Serial Block Face Scanning Electron Microscopy

Serial block-face scanning electron microscopy (SBFSEM) has revolutionized the field of three-dimensional (3D) microscopy, providing researchers with unprecedented capabilities to visualize the ultrastructure of cells and tissues at the nanometer scale. This powerful technique combines the high resolution of scanning electron microscopy (SEM) with automated serial sectioning, enabling the acquisition of large, contiguous 3D datasets. SBFSEM has found widespread applications in various disciplines, including neuroscience, cell biology, developmental biology, and materials science, offering unique insights into the complex organization of biological and non-biological specimens.

Understanding Serial Block-Face Scanning Electron Microscopy

SBFSEM is a 3D electron microscopy technique that involves the iterative process of imaging the surface of a resin-embedded sample block, removing a thin layer of material using an ultramicrotome within the SEM chamber, and then imaging the freshly exposed surface. This cycle is repeated hundreds or even thousands of times, generating a stack of high-resolution images that can be computationally aligned and reconstructed to create a 3D representation of the sample.

The key components of an SBFSEM system include:

• Scanning Electron Microscope (SEM): Provides high-resolution imaging of the sample surface using a focused electron beam.
• Ultramicrotome: A precision cutting instrument integrated within the SEM chamber that removes thin sections of the sample block.
• Detector: Captures the backscattered electrons (BSE) or secondary electrons (SE) emitted from the sample surface, forming the image.
• Automated Control System: Manages the imaging and sectioning process, ensuring precise and consistent data acquisition.
• Image Processing Software: Used for image alignment, 3D reconstruction, and data analysis.

The SBFSEM Workflow: A Step-by-Step Guide

The SBFSEM workflow typically involves the following steps:

1. Sample Preparation: The sample is carefully prepared to preserve its ultrastructure and enhance contrast. This usually involves chemical fixation, heavy metal staining, and embedding in a resin that is suitable for ultramicrotomy.
2. Block Trimming and Mounting: The resin-embedded sample is trimmed to a suitable size and shape, and then mounted on a specimen holder that can be precisely positioned within the SEM.
3. System Setup and Calibration: The SBFSEM system is calibrated to ensure accurate sectioning and imaging parameters. This includes setting the appropriate accelerating voltage, beam current, and detector settings.
4. Automated Serial Sectioning and Imaging: The automated control system initiates the serial sectioning and imaging process. The ultramicrotome removes a thin layer of material (typically 25-100 nm), and the SEM acquires an image of the freshly exposed surface. This cycle is repeated until the desired depth of the sample has been imaged.
5. Image Alignment and 3D Reconstruction: The stack of images is aligned to correct for any distortions or shifts that may have occurred during the sectioning and imaging process. This is typically done using specialized image processing software. Once the images are aligned, a 3D reconstruction of the sample can be generated.
6. Data Analysis and Visualization: The 3D reconstruction can be analyzed and visualized using a variety of software tools. This allows researchers to explore the ultrastructure of the sample, identify specific features of interest, and quantify their spatial relationships.

Advantages of SBFSEM

SBFSEM offers several advantages over traditional electron microscopy techniques:

• High Resolution: SBFSEM provides high-resolution images of the sample surface, allowing for detailed visualization of cellular and subcellular structures.
• Large Volume Imaging: SBFSEM can be used to image large volumes of tissue, providing a comprehensive 3D view of the sample.
• Automated Data Acquisition: The automated nature of SBFSEM allows for the acquisition of large datasets with minimal user intervention.
• Reduced Sectioning Artifacts: Because the sectioning is performed within the SEM chamber, SBFSEM minimizes sectioning artifacts that can occur with traditional ultramicrotomy.
• Precise Z-Resolution: The thickness of the sections removed by the ultramicrotome can be precisely controlled, providing accurate z-resolution in the 3D reconstruction.

Limitations of SBFSEM

Despite its advantages, SBFSEM also has some limitations:

• Sample Preparation: The sample preparation process for SBFSEM can be time-consuming and requires specialized expertise.
• Data Size: SBFSEM datasets can be very large, requiring significant computational resources for image processing and analysis.
• Imaging Speed: The imaging speed of SBFSEM is limited by the time required for sectioning and image acquisition.
• Beam-Induced Damage: The electron beam can cause damage to the sample, which can affect the quality of the images.
• Contrast Limitations: The contrast in SBFSEM images is often limited by the staining methods used to prepare the sample.

Applications of SBFSEM

SBFSEM has found widespread applications in various fields of research:

• Neuroscience: SBFSEM is used to study the structure and connectivity of neurons in the brain, providing insights into neural circuits and synaptic plasticity.
• Cell Biology: SBFSEM is used to visualize the ultrastructure of cells and organelles, providing information about cellular processes and disease mechanisms.
• Developmental Biology: SBFSEM is used to study the development of tissues and organs, providing insights into morphogenesis and cell differentiation.
• Materials Science: SBFSEM is used to characterize the 3D structure of materials, providing information about their properties and performance.
• Connectomics: SBFSEM is a key tool in connectomics, the study of the complete neural circuits in the brain. It allows researchers to trace the connections between individual neurons and map out the entire neural network.
• Cancer Research: SBFSEM is used to study the ultrastructural changes in cancer cells and tissues, providing insights into tumor development and metastasis.
• Infectious Disease Research: SBFSEM is used to visualize the interaction between pathogens and host cells, providing insights into the mechanisms of infection.

Sample Preparation Techniques for SBFSEM

Effective sample preparation is crucial for obtaining high-quality SBFSEM data. The goal is to preserve the ultrastructure of the sample, enhance contrast, and ensure that the sample is compatible with ultramicrotomy. Several techniques are commonly used for SBFSEM sample preparation:

1. Chemical Fixation: The sample is typically fixed using a combination of aldehydes (e.g., glutaraldehyde and formaldehyde) to crosslink proteins and stabilize the cellular structures.
2. Heavy Metal Staining: Heavy metals such as osmium tetroxide, uranyl acetate, and lead citrate are used to enhance contrast by binding to cellular components.
3. Dehydration: The sample is dehydrated using a series of increasing ethanol concentrations to remove water.
4. Resin Infiltration and Embedding: The dehydrated sample is infiltrated with a resin, such as epoxy resin or acrylic resin, which provides support for ultramicrotomy. The resin is then polymerized to create a hard block.
5. Block Trimming: The resin block is trimmed to a suitable size and shape for mounting on the ultramicrotome.

Enhancing Contrast in SBFSEM

Contrast enhancement is a critical aspect of SBFSEM sample preparation. Several techniques can be used to improve contrast:

• En Bloc Staining: This involves staining the sample with heavy metals before embedding in resin. This allows the heavy metals to penetrate deep into the tissue, providing uniform contrast throughout the sample.
• Reduced Osmium Tetroxide Protocol: This protocol uses a lower concentration of osmium tetroxide, which can reduce the formation of osmium precipitates and improve contrast.
• Uranyl Acetate Replacement: Uranyl acetate is a commonly used heavy metal stain, but it is radioactive and can be difficult to obtain. Several alternatives to uranyl acetate have been developed, such as tannic acid and N-methyl-d-glucamine tungstate.
• Conductive Coatings: Applying a thin conductive coating, such as gold or platinum, to the surface of the sample can improve image quality by reducing charging artifacts.

Image Processing and Analysis for SBFSEM Data

SBFSEM generates large datasets that require specialized image processing and analysis techniques. The goal is to align the images, correct for distortions, and extract meaningful information from the 3D reconstruction.

1. Image Alignment: The images in the SBFSEM stack are typically aligned using software that automatically detects and matches features in adjacent images. This corrects for any shifts or rotations that may have occurred during the sectioning and imaging process.
2. 3D Reconstruction: Once the images are aligned, a 3D reconstruction of the sample can be generated. This involves interpolating between the images to create a continuous 3D volume.
3. Segmentation: Segmentation is the process of identifying and outlining specific structures in the 3D reconstruction. This can be done manually or using automated segmentation algorithms.
4. Quantification: Once the structures of interest have been segmented, their properties can be quantified. This includes measuring their size, shape, volume, and spatial relationships.
5. Visualization: The 3D reconstruction can be visualized using a variety of software tools. This allows researchers to explore the ultrastructure of the sample, identify specific features of interest, and create animations and renderings.

Software Tools for SBFSEM Image Processing and Analysis

Several software tools are available for processing and analyzing SBFSEM data:

• Amira: A commercial software package that provides a wide range of tools for image processing, 3D reconstruction, segmentation, and visualization.
• Imaris: Another commercial software package that is popular for its powerful segmentation and analysis tools.
• Fiji/ImageJ: An open-source image processing program that is widely used in the scientific community. Fiji/ImageJ can be extended with plugins to perform a variety of SBFSEM image processing tasks.
• Ilastik: A machine learning-based software tool that can be used for automated segmentation of SBFSEM data.
• Mitochondria Analyzer: An open-source tool designed specifically for the automated segmentation and analysis of mitochondria in electron microscopy images.

Future Directions in SBFSEM

SBFSEM technology is constantly evolving, with ongoing developments aimed at improving its resolution, speed, and versatility. Some of the future directions in SBFSEM research include:

• Higher Resolution Imaging: Efforts are underway to develop SBFSEM systems that can achieve even higher resolution, allowing for the visualization of smaller structures.
• Faster Imaging Speeds: New techniques are being developed to increase the imaging speed of SBFSEM, allowing for the acquisition of larger datasets in a shorter amount of time.
• Improved Contrast Enhancement: Researchers are exploring new staining methods and contrast agents to improve the contrast in SBFSEM images.
• Integration with Other Imaging Modalities: SBFSEM is being integrated with other imaging modalities, such as light microscopy and focused ion beam scanning electron microscopy (FIB-SEM), to provide complementary information about the sample.
• Automation and Artificial Intelligence: The use of automation and artificial intelligence is becoming increasingly important in SBFSEM research. Automated segmentation algorithms and machine learning-based tools are being developed to streamline the image processing and analysis workflow.
• Correlative Light and Electron Microscopy (CLEM): Combining light microscopy with SBFSEM allows researchers to identify specific regions of interest using light microscopy and then visualize their ultrastructure using SBFSEM.
• Volume EM with Deep Learning: Deep learning techniques are being applied to volume electron microscopy data to automate segmentation, improve image quality, and extract more information from the data.

Conclusion

Serial block-face scanning electron microscopy (SBFSEM) is a powerful technique that has transformed the field of 3D microscopy. Its ability to acquire high-resolution, large-volume datasets has enabled researchers to gain unprecedented insights into the ultrastructure of cells, tissues, and materials. While SBFSEM has some limitations, its advantages make it an invaluable tool for a wide range of applications. As the technology continues to evolve, SBFSEM is poised to play an even greater role in advancing our understanding of the complex world around us. From unraveling the intricacies of neural circuits to elucidating the mechanisms of disease, SBFSEM is empowering researchers to explore the nanoscale world in unprecedented detail. With ongoing advancements in sample preparation, image processing, and automation, SBFSEM will continue to drive discovery and innovation in various fields of science and technology.
